ออดิโออินเตอร์เฟส Steinberg UR24C USB Audio Interface
USB ออดิโออินเตอร์เฟส Steinberg UR24C, USB 3.0 Audio Interface, 2-in/4-out, 32-bit/192kHz, with 2 Mic/Line Inputs, MIDI I/O, USB Bus Power, 2 Monitor Modes DAW and DJ, Cubase AI and Cubasis LE software included
ราคาไม่รวมภาษีมูลค่าเพิ่ม…..
฿8,400.00 ฿7,800.00
Description
Steinberg UR24C 2×4 USB Gen 3.1 Audio Interface
USB ออดิโออินเตอร์เฟส Steinberg UR24C, USB 3.0 Audio Interface, 2-in/4-out, 32-bit/192kHz, with 2 Mic/Line Inputs, MIDI I/O, USB Bus Power, 2 Monitor Modes DAW and DJ, Cubase AI and Cubasis LE software included
The Steinberg UR24C 2×4 USB Gen 3.1 Audio Interface is designed for two primary purposes: to give you impeccable sound recording on the go and to facilitate cue mixes during live sets. Make use of its 32-bit converters for a wide dynamic range, and record at sample rates of up to 192 kHz for capturing detailed sonic nuances. Whether you are recording yourself at the home studio or performing DJ sets at live shows, the UR24C will come in handy.
The interface offers two combo XLR-1/4″ inputs, one of which can accept Hi-Z instruments, so you can record your basses and guitars direct, with fine degrees of resolution. Connect your monitors (available separately) via two 1/4″ TRS jacks in the back of the unit, or make use of the 1/4″ headphone output on the front panel to monitor privately. You’ll also find four line outputs, which can come in handy for providing click tracks to band members on stage or backing tracks to the house.
While you’re recording, make use of the Mix knob to ensure that you hear your sound free of latency. When you’re DJing, put the Mix knob into DJ mode, and put your cue mix on the right side of the headphones, and your mono master on the left. Furthermore, connect your favorite MIDI devices over the 5-pin DIN MIDI I/O jacks.
The interface can communicate over a USB GEN 3.1 connection for seamless integration with Mac and Windows computers. The port is also backwards compatible for USB 2.0. Even iOS devices running iOS 10 or later are supported, so you can record straight to your iPad.
Multiple effects are included, such as REV-X reverb and guitar amplifier emulations. For home recording and production, Cubasis LE and Cubase AI are included, as is a software, zero-latency monitoring matrix called dspMixFx. The interface is powered over USB, though you can also use a separately available 5V DC adapter.
Features:
- Windows, Mac OS, and iOS cross-platform compatibility for superior flexibility
- MIDI I/O syncs effortlessly with outside hardware
- Latency-free DSP monitoring
- USB 3.0 to USB-C connector can connect to most modern devices
- 2 Class-A D-PRE microphone preamps with +48V phantom power
- Cubase AI and Cubasis LE software included
- Portable design and rugged housing
Specifications
| Channels of I/O | Analog: 2 Inputs / 4 Outputs |
| Max Sample Rate/Resolution | 192 kHz / 32-Bit |
| Display and Indicators | 2 x LEDs (Peak) 1 x LED (+48 V) 1 x LED (Host Connection) |
| Host Connection | 1 x USB Type-C (USB 3.0 / 3.1 Gen 1) |
| Analog I/O | 2 x Combo XLR-1/4″ TRS Balanced/Unbalanced Mic/Line/Hi-Z Input 2 x 1/4″ TRS Balanced Monitor Output 2 x Stereo RCA Coaxial Unbalanced Line Output 1 x 1/4″ TRS Unbalanced Headphone Output |
| Phantom Power | +48 V (Selectable on Individual Inputs) |
| Digital I/O | None |
| MIDI I/O | 1 x DIN 5-Pin Input 1 x DIN 5-Pin Output |
| Frequency Response | Mic Inputs: 20 Hz to 22 kHz 0/-0.3 dB Monitor Outputs: 20 Hz to 22 kHz 0/-0.2 dB Line Outputs: 20 Hz to 22 kHz +0/-0.2 dB |
| Gain/Trim Range | Mic Inputs: +6 dB to +60 dB Hi-Z Inputs: +0.8 dB +54.8 dB Line Inputs: -10 dB to +44 dB |
| Max Input Level | Mic Inputs: +6 dBu (Balanced) Hi-Z Inputs: +9 dBV (Unbalanced) Line Inputs: +22 dBu (Balanced) |
| Max Output Level | Line Outputs, Monitor Outputs: +12 dBu (Balanced) |
| Headphone Output Power | 15 mW per Channel |
| Dynamic Range | Inputs: 102 dBA Outputs: 106 dBA |
| Impedance | Mic Inputs: 6 Kilohms (Balanced) Hi-Z Inputs: 1 Megohms (Unbalanced) Line Inputs: 12 Kilohms (Balanced) Outputs: 150 Ohms (Balanced) Headphone Outputs: 40 Ohms (Unbalanced) |
| THD+N | Mic Inputs: 0.0035% Outputs: 0.002% |
| Sample Rates | Up to 192 kHz |
| Bit Depths | Up to 32-Bit |
| OS Compatibility | Windows 7 / 8.1 / 10 macOS 10.12 or Later iOS 10 or Later |
| Processor Requirement | Mac: 2 GHz Intel Core i3 PC: 2 GHz Intel Core i3 PC: 2 GHz AMD |
| RAM Requirements | 2 GB |
| Storage Requirements | 1200 MB |
| Minimum Display Resolution | 1280 x 800 |
| Internet Connection | Required for Registration, Software/Driver Download |
| Power Requirements | AC/DC Power Adapter (Not Included), USB Bus Power |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Dimensions | 7.8 x 6.26 x 1.85″ / 19.8 x 15.9 x 4.7 cm |
| Weight | 2.4 lb / 1.1 kg |
