เครื่องรับสัญญาณ SHURE P10R+ Bodypack Receiver for PSM 1000
อุปกรณ์รับสัญญาณไร้สายแบบ bodypack SHURE P10R+ สำหรับชุดอินอียร์ PSM1000 Monitor Systems, Automatic Gain Control, RF Scan, Slim and Compact Aluminum Body, 4-band parametric EQ added, Power-Save Mode added
ราคาไม่รวมภาษีมูลค่าเพิ่ม…..
฿58,400.00 ฿35,900.00
Description
SHURE P10R+ Diversity Bodypack Receiver (Q12: 748 to 758 MHz)
อุปกรณ์รับสัญญาณไร้สายแบบ bodypack SHURE P10R+ สำหรับชุดอินอียร์ PSM1000 Monitor Systems, Automatic Gain Control, RF Scan, Slim and Compact Aluminum Body, 4-band parametric EQ added, Power-Save Mode added
Shure’s P10R+ is a low-profile, diversity bodypack receiver for use with the PSM® 1000 Personal Monitor System. The P10R+ twin-antenna diversity Bodypack Receiver brings personal monitoring to its highest level yet, putting category-leading audio quality, robust RF performance, and touring-grade features right at your fingertips.
Its advanced digital signal processing technology delivers unparalleled audio quality with more headroom, better stereo separation, and higher fidelity. With premium features like full bandwidth RF scan, Precision Front-End RF Filtering, and Automatic RF Gain Control, P10R+ meets the needs of professional audio applications of all sizes, including IEM and IFB applications.
Features:
- Advanced digital signal processing technology yields incredible headroom, stereo separation, and audio fidelity
- Upgraded headphone amplifier for an all-around better audio experience
- Precision front-end RF filtering reduces RF interference for a stronger RF signal, fewer dropouts, and fewer artifacts
- Networked control via Ethernet connection simplifies setup and enables remote control via Shure’s Wireless Workbench software
- CueMode allows monitoring of different stage mixes and storing of up to 20 separate channels for quick and easy reference
- MixMode technology combines two separate audio channels for simultaneous listening in both ears
- Automatic RF gain control thwarts signal distortion due to RF overload before it can affect your performance
- Patented Audio Reference Companding supplies a natural and transparent sound
- Advanced Rechargeability Options
Specifications
| RF Filter Range | Tri-Band: -3 dB at 30.5 MHz from the Center Frequency of Each Band |
| RF Gain | Active: 31 dB (Adjusts RF Sensitivity to Provide More RF Dynamic Range) |
| RF Sensitivity | 2.2 μV (20 dB SINAD) |
| Squelch Threshold | 22 dB SINAD (±3 dB), Default Setting |
| Adjacent Channel Rejection | >70 dB |
| Intermodulation Attenuation | >70 dB |
| Blocking | >80 dB |
| Image Rejection | >90 dB |
| Image Rejection | >90 dB |
| Audio Output Power | 100 mW per Output (1 kHz @ <1% Distortion, Peak Power, @ 16 Ohms) |
| Minimum Load Impedance | 4 Ohms |
| Output Impedance | <1 Ohm |
| 4-Band Parametric Equalizer | Low-Shelf Selectable Gain: ±2, ±4, ±6 dB @ 100 Hz Low-Mid Selectable Gain: ±2, ±4, ±6 dB @ 160, 250, 400, 500, 630 Hz Selectable Q: 0.7, 1.4, 2.9, 5.0, 11.5 High-Mid Selectable Gain: ±2, ±4, ±6 dB @ 1, 1.6, 2.5, 4, 6.3 kHz Selectable Q: 0.7, 1.4, 2.9, 5.0, 11.5 High-Shelf Selectable Gain: ±2, ±4, ±6 dB @ 10 kHz |
| Volume Limiter | Selectable: 0 to -48 dB in 3 dB Steps |
| Volume Lock | Selectable: 0 to -70 dB Limits Volume Adjustment Knob Selected Value Analogous to Volume Knob Increment |
| Battery Life | 4-6 Hours (Continuous Use) with AA Batteries |
| Dimensions | 3.9 x 2.6 x 0.9″ / 9.9 x 6.6 x 2.3 cm |
| Weight | 5.6 oz / 158.0 g without Batteries |
Downloads
ดาวน์โหลด Data Sheet SHURE P10R+
