ออดิโออินเตอร์เฟส RCF TRK PRO2 USB Audio Interface

Name: ออดิโออินเตอร์เฟส RCF TRK PRO2 USB Audio Interface
Price: 11340.00 THB
Availability: InStock

ออดิโออินเตอร์เฟส RCF TRK PRO2, 2-in/2-out USB 2.0 Bus-powered Audio Interface, 24-bit/192kHz, with 2 Mic/Line/Inst Input, Balanced Output, Headphone Output, Preamp, 48V Phantom Power and Hi-Z Compatibility Mac/PC, Includes Rackmount Ears

ราคาสินค้าไม่รวมภาษีมูลค่าเพิ่ม

฿11,340.00

สอบถามและสั่งซื้อสินค้า

Category: ออดิโออินเตอร์เฟส (Audio Interface) Tag: RCF

Description

RCF TRK PRO2 USB Audio Interface

RCF TRK PRO2 hardware interface packs a robust and well-thought USB 2.0 studio-in-a-box with all the connectivity required for microphones, musical instruments, or line-level signals to a computer running macOS or Windows.

The 2-channel internal linear preamp circuit allows the connection of 48V phantom-powered microphones and Hi-Z level instruments. Input signals can be routed to DAW (Digital Audio Workstation) at up to 24-bit, 192 kHz resolution; similarly, software monitoring and direct monitoring can be routed to the balanced outputs with variable mixing ratio.

The interface can be connected to an amplifier and speakers, powered monitors, headphones, an analog mixer, or other analog audio devices.

Features:

2 In 2 Out USB 2.0 Bus-Powered Audio Interface
Up to 24-Bit/192kHz
2 Mic and Instrument/Line Combo input
High-Quality Preamps
Balanced Output
Independent Headphone Volume Control
Zero-latency monitoring
Independent Gain Control with Signal-Peak LED
Perfect for RDNet Measures
Rack Mount Ears included

Specifications

Channels of I/O	No
Built-In DSP	No
Maximum Sampling Rate	192 kHz / 24-Bit
Number of Microphone Inputs	1
Built-In Microphone	No
Input Level Adjustment	2x Knob

Signal Processing

Pad	No
High-Pass Filter	No
Solo/Mute	No

Connectivity

Analog Audio I/O	2x Combo XLR-1/4″ TRS Balanced/Unbalanced Mic/Line/Hi-Z Input (Front Panel) 1x 1/4″ TRS Unbalanced Headphone Output (Front Panel) 2x 1/4″ TRS Balanced Monitor Output
Phantom Power	48 V, Selectable On/Off (Applied to All Inputs)
Digital Audio I/O	No
Host Connection	1x USB-B (Class-Compliant)
Host Connection Protocol	USB 2.0
USB (Non-Host)	No
Sync I/O	No
Network I/O	No
MIDI I/O	No
Expansion Slots	No
Wireless	No

Performance

Frequency Response	Combo XLR-1/4″ Mic, Line, Hi-Z Inputs: 20 Hz to 20 kHz
Maximum Input Level	Combo XLR-1/4″ Mic Inputs: +9 dBu (Balanced) Combo XLR-1/4″ Line Inputs: +20 dBu (Balanced) Combo XLR-1/4″ Hi-Z Inputs: +10 dBu (Unbalanced)
Headphone Output Power	1/4″: 114 mW into 500 Ohms (Unbalanced)
Impedance	Combo XLR-1/4″ Mic Inputs: 3.5 Kilohms (Balanced, Mic Level) Combo XLR-1/4″ Line Inputs: 15 Kilohms (Balanced, Line Level) Combo XLR-1/4″ Hi-Z Inputs: 1 Megohm (Unbalanced) Combo XLR-1/4″ Headphone Outputs: < 10 Ohms (Unbalanced)
Dynamic Range	Combo XLR-1/4″ Analog/Mic/Line/Hi-Z Inputs: 107 dBu (A-Weighted) 1/4″ Analog/Monitor Outputs: 107 dB (A-Weighted)
THD+N	Combo XLR-1/4″ Mic/Line Inputs: < 0.0011% (20 Hz to 20 kHz, at -1 dBFS) Combo XLR-1/4″ Hi-Z Inputs: 107 dB (A-Weighted) 1/4″ Monitor Outputs: < 0.0012% (20 Hz to 20 kHz, at -1 dBFS)
EIN	Combo XLR-1/4″ Mic Inputs: < -120 dB

Digital Audio

Sample Rates	USB-A Output: 44.1 / 48 / 88.2 / 96 / 176.4 / 192 kHz (AD/DA Conversion, Input/Output, Mac and PC, Playback, Record)
Sample Rate Conversion	No
Bit Depths	16 / 24-Bit (AD/DA Conversion, Recording, Playback)
Latency	Zero-Latency Direct Monitoring
Sync Sources	No

Audio Storage & Playback

Media/Memory Card Slot

Compatibility

OS Compatibility	Windows 10 or Later / macOS
Mobile Device Compatibility	Android Smartphone Android Tablet iPad iPhone
Required Hardware	USB-A Port

Power

Power Requirements

USB Bus Power

Physical

Rackmount Size	1 U (with Included Hardware, 1/2-Rack)
Certifications	CE, WEEE
Dimensions	8.27 x 4.95 x 1.81″ / 21.01 x 12.57 x 4.6 cm
Weight	1.8 lb / 0.8 kg
