ลำโพงซับเบส RCF HDL38-AS Active Flyable Subwoofer Module
ลำโพงซับเบสไลน์อาเรย์ Active มีกำลังขยายในตัว RCF HDL38-AS มีขนาดดอกลำโพง 18 นิ้ว Neodymium Woofer 4.0 นิ้ว voice coil, 3200W peak class-D Amplifier, 30-140 Hz frequency response, RDNet Networked Management, For Use with HDL 30-A Array System
ราคาสินค้าไม่รวมภาษีมูลค่าเพิ่ม…เป็นราคาใบละ…
฿379,620.00
Description
RCF HDL38-AS Active Flyable Subwoofer Module 18″
ลำโพงซับเบสไลน์อาเรย์ Active มีกำลังขยายในตัว RCF HDL38-AS มีขนาดดอกลำโพง 18 นิ้ว Neodymium Woofer 4.0 นิ้ว voice coil, 3200W peak class-D Amplifier, 30-140 Hz frequency response, RDNet Networked Management, For Use with HDL 30-A Array System
The HDL 38-AS is the ideal flyable bass complement for the HDL 30-A array system. It features one 4.0” voice coil, 18” Neodymium woofer to handle 136 dB SPL Max from 30 Hz to 140 Hz with the maximum linearity and low distortion.
The HDL 38-AS is perfect to create flown systems for theatrical and indoor requirements. The built-in 3200W class-D amplifier delivers excellent playback clarity and up to 136 decibels SPL max. Due to its compatibility with RDNet – remote monitoring and control, the HDL 38-AS is part of the professional HDL System.
Features:
- 136 dB Max SPL
- 3200W peak class-D Amplifier
- 30-140 Hz frequency response
- RDNet Networked Management
- 1×18” Neodymium Woofer, 4.0” voice coil
Specifications
| Configuration | Active Subwoofer |
| Enclosure Type | Line Array Subwoofer |
| Total Power Capacity | 3200 W Peak 1600 W RMS |
| Amplifier Power Rating | 3200 W Peak 1600 W RMS |
| Amplifier Class | Class-D |
| MF Driver | None |
| LF Driver | 1 x 18″ / 45.7 cm Woofer |
| LF Voice Coil | 4″ / 10.2 cm |
| Magnet | Neodymium |
| Frequency Response | 30 Hz to 140 Hz |
| Maximum SPL | 136 dB |
| Input Sensitivity | +4 dBu |
| Protections | Output Limiter, Thermal |
| Audio I/O | 1 x XLR 3-Pin Female Balanced/Unbalanced Line Input (Lockable) 1 x XLR 3-Pin Male Balanced/Unbalanced Line Thru |
| Network I/O | 1 x etherCON (RDNet) Input 1 x etherCON (RDNet) Output |
| USB | None |
| Wireless Connectivity | None |
| EQ | Yes |
| Parametric EQ | Yes |
| Semi-Parametric EQ | None |
| Alignment Delay | Yes |
| Phase Adjustment | Yes |
| Digital Signal Processing | Delay, FIR Filter, User Settings |
| AC Input Power | 115 VAC, 60 Hz 230 VAC, 50 Hz |
| AC Power Connector | 1 x powerCON Input (Locking) 1 x powerCON Output (Locking) |
| Mounting | 1 x Bracket Point (Each Side) 1 x Bracket Point (Rear) |
| Handles | 1 x Each Side |
| Cooling | Convection |
| Construction Material | Metal Grille, Plywood |
| Certifications | CE, as per Manufacturer |
| Dimensions | 19.8 x 27.6 x 24.5″ / 50.3 x 70.1 x 62.2 cm |
| Weight | 107.4 lb / 48.7 kg |
