อนาล็อคมิกเซอร์ RCF F 16XR 16-Channel Mixer with Multi-FX & Recording

Name: อนาล็อคมิกเซอร์ RCF F 16XR 16-Channel Mixer with Multi-FX & Recording
Price: 33510.00 THB
Availability: InStock

เครื่องผสมสัญญาณเสียงมิกเซอร์ RCF F 16XR แบบอนาล็อค, 16-Channel Mixer with Multi-FX Stereo Recording and Playback via USB port, 60 mm faders, 2-In/2-Out USB up to 48 kHz, PRO DSP FX onboard with 16 presets, USB Works with Windows, Mac, and iOS

ราคาสินค้าไม่รวมภาษีมูลค่าเพิ่ม

฿33,510.00

สอบถามและสั่งซื้อสินค้า

Category: อนาล็อคมิกเซอร์ (Analog Mixer) Tag: RCF

Description

RCF F-16XR 16-Channel Mixer with Multi-FX and Stereo USB Interface

The RCF F-16XR is a mixer designed for live sound applications. It has 10 mic preamps, 8 mono line inputs, and four stereo line inputs. Line connections can be made over 1/4″ connections or RCA terminations. You’ll find 3-band EQs on the mono channels, and 3-band EQs on the stereo line inputs. Single-knob compressors are available on channels 1 through 6, and phantom power is available on all microphone inputs.

24-bit effects are on hand to give you reverb, echo, delay, flanger, and more. Route to main outputs, monitors, or headphones, thanks to the comprehensive output section. With the USB output, you can record stereo audio on Mac, Windows, or iOS devices (with compatible adapters).

Features:

10 Mic preamp inputs, 4 mono line inputs
4 Stereo line inputs
PRO DSP FX onboard with 16 presets
Stereo recording and playback via USB port
6 single control compressors
Balanced main output +28 dB (Stereo XLR + TRS)
Two stereo output busses and 4 aux sends (2 pre, 1 pre/post, 1 post)
60 mm faders
Internal universal power supply
Designed and engineered in Italy

Specifications

Inputs

Input Connections	10 x XLR Inputs 16 x 1/4″ Inputs (4 x Stereo Pairs, 8 Mono) 4 x RCA Inputs (2 x Stereo Pair) 1 x 1/4″ Footswitch Input
Gain Range	0 to -50 dB
Input Impedance	Mic: 14 Kilohms Line: 21 Kilohms Stereo Line: 14 Kilohms
Frequency Response	20 Hz to 20 kHz
Gain Selection	20 dB to -30 dB
Low Cut Filters	80 Hz
Phantom Power	+48 V

Outputs

Output Connections	2 x XLR Main Outputs 2 x 1/4″ Main Outputs 2 x 1/4″ CTL Room Outputs 4 x 1/4″ Auxiliary Outputs 1 x 1/4″ Headphones Output
Output Level	28 dBu
Headphone Impedance	150 Ohms

System Specifications

Compressor	Single-Control Compressors on Channels 1 through 6
Equalization	Input Channels: 1 Semi Parametric / 2 Shelving High: ±15 dB at 10 kHz, Shelving Mid: ±15 dB at Frequency Selectable from 100 Hz to 8 kHz, Bell Low: ±15 dB at 100 Hz, Shelving
USB Audio	Type-B, 2-Channel I/O, 44.1 or 48 kHz Sample Rate
Case Material	Metal
Frequency Response	20 Hz to 20 kHz
THD+N	< 0.02% (20 dB Gain, 0 dBu Out, A-Weighted)
Voltage Requirements	100 to 240 VAC
Power Consumption	30 W
Power Supply	Internal
Dimensions (D x H x W)	16 x 4.2 x 18.8″ / 40.6 x 10.7 x 47.9 cm
Weight	14.1 lb / 6.4 kg
