ออดิโออินเตอร์เฟส PreSonus Studio68 USB 2.0 Audio/MIDI Interface
USB ออดิโออินเตอร์เฟส PreSonus Studio 68, 4 Analog Inputs and 6 Analog Outputs, USB 2.0 Recording System, Four XMAX-L Solid-State Mic Preamps, 24-Bit/192 kHz, Direct Monitoringuded
ราคาสินค้าไม่รวมภาษีมูลค่าเพิ่ม…
฿11,900.00 ฿10,900.00
Description
PreSonus Studio 68 6×6 192 kHz, USB 2.0 Audio/MIDI Interface
USB ออดิโออินเตอร์เฟส PreSonus Studio 68, 4 Analog Inputs and 6 Analog Outputs, USB 2.0 Recording System, Four XMAX-L Solid-State Mic Preamps, 24-Bit/192 kHz, Direct Monitoring, Mac and Windows Compatible, Studio One Artist Included
The Studio 68 from Presonus is a 6×6 USB 2.0 audio and MIDI interface featuring two front-panel combo mic-and-line/instrument inputs and two rear-panel mic/line combo inputs, each with XMAX-L solid-state mic preamps. In addition to the main outputs, there is another set of stereo line outputs for mixing or speaker monitor-switching.
A stereo headphone output features a Cue Mix A/B, which toggles between two mixes, well suited for live-performance DJs or for listening to a performer’s monitor mix. Additionally, the Studio 68 features a 9-pin D-sub connector which connects to a breakout cable and features MIDI I/O connectors and S/PDIF digital I/O—it is a complete recording solution and ships with Presonus’ Studio One Artist software.
Features:
- USB 2.0, 6×6 audio interface (4×4 at 192 kHz)
- 24-bit resolution; 44.1, 48, 88.2, 96, 176.4, and 192 kHz sampling rates
- Two mic/instrument/line inputs with XMAX Class-A mic preamps
- Two mic/line inputs with XMAX Class-A mic preamps
- +48V phantom power (global)
- Two balanced ¼” TRS line outputs for monitor mixing or speaker switching
- Two balanced ¼” TRS main outputs with front-panel level control
- Six ladder-style LED level meters (4 input, 2 main output)
- Stereo headphone output with Cue Mix A/B
- Direct monitoring, MIDI I/O, S/PDIF I/O
- Studio One Artist included,
- Include Studio Magic Plug-in Suite with Maag Audio EQ 2, SPL Attacker, Arturia instruments, and more
Specifications
General |
|
|---|---|
| Sample Rates | 44.1, 48, 88.2, 96, 176.4, or 192 kHz |
| Converter Resolution | 24 bit |
| Converter Dynamic Range | 114 dB |
| Converter Dynamic Range | 114 dB |
Microphone Inputs |
|
|---|---|
| Maximum Level | +16 dBu (balanced, min gain) |
| Gain Range | 80 dB |
| Frequency Response | 20 Hz – 20 kHz (±0.15 dB, min gain, 48 kHz) |
| Dynamic Range | 114 dB (A-wtd, min gain) |
| THD + N | 0.007% (1 kHz, -1 dBFS, min gain) |
| EIN | -130 dBu (max gain, 150Ω, A-wtd) |
| Input Impedance | 1.6 kΩ |
| Phantom Power | +48 VDC (10 mA per channel) |
Line Inputs |
|
|---|---|
| Maximum Level | +22 dBu (balanced, min gain) |
| Gain Range | 40 dB |
| Frequency Response | 20 Hz – 20 kHz (±0.15 dB, min gain, 48 kHz) |
| Dynamic Range | 113.9 dB (A-wtd, min gain) |
| THD + N | 0.007% (1 kHz, -1 dBFS, min gain) |
| Input Impedance | 10 kΩ |
Instrument Inputs |
|
|---|---|
| Maximum Level | +15 dBu (unbalanced, min gain) |
| Gain Range | 80 dB |
| Frequency Response | 20 Hz – 20 kHz (±0.1 dB, 48 kHz, min gain) |
| Dynamic Range | 114.7 dB (A-wtd, min gain) |
| THD + N | 0.012% (1 kHz, -1 dBFS, min gain) |
| Input Impedance | 1 MΩ |
Line Outputs (Mains) |
|
|---|---|
| Type | ¼” TRS Female, DC Coupled |
| Maximum Level | +18 dBu (balanced) |
| Frequency Response | 20Hz – 20kHz (±0.2dB, unity gain, 48 kHz) |
| Dynamic Range | 109 dB (A-wtd) |
| THD + N | 0.001% (1 kHz, -1 dBFS) |
Line Outputs (3/4) |
|
|---|---|
| Type | ¼” TRS Female, DC coupled |
| Maximum Level | +18 dBu (balanced) |
| Frequency Response | 20 Hz – 20 kHz (+/- 0.2 dB, unity gain, 48 kHz) |
| Dynamic Range | 109 dB (A-wtd) |
| THD + N | 0.0015% (1 kHz, -1 dBFS) |
Headphone Outputs |
|
|---|---|
| Maximum Power | 150 mW/channel (56Ω load) |
| Frequency Response | 20 Hz – 20 kHz (±0.2 dB, 56Ω load, 48 kHz) |
| Dynamic Range | 107 dB (A-wtd, 56Ω load) |
| THD + N | 0.002% (1 kHz, -1 dBFS, no load) |
| Impedance Working Range | 32Ω to 300Ω |
Physical |
|
| Height | 1.75″ (44 mm) |
| Width | 9″ (229 mm) |
| Depth | 5.5″ (140 mm) |
| Weight | 2.4 lbs (1 kg) |
