ออดิโออินเตอร์เฟส PreSonus Studio 1824 USB 2.0 Audio Interface

Name: ออดิโออินเตอร์เฟส PreSonus Studio 1824 USB 2.0 Audio Interface
Price: 15900.00 THB
Availability: InStock

USB ออดิโออินเตอร์เฟส PreSonus Studio 1824, High-Speed USB 2.0 Computer Interface, 24-Bit / 192 kHz, 2 x Mic/Instrument/Line Inputs, 6 x Mic/Line Inputs

ราคาสินค้าไม่รวมภาษีมูลค่าเพิ่ม…

~~฿18,900.00~~ ฿15,900.00

สอบถามและสั่งซื้อสินค้า

Category: ออดิโออินเตอร์เฟส (Audio Interface) Tag: PreSonus

Description

PreSonus Studio 1824 18×18 USB 2.0 Audio Interface

USB ออดิโออินเตอร์เฟส PreSonus Studio 1824, High-Speed USB 2.0 Computer Interface, 24-Bit / 192 kHz, 2 x Mic/Instrument/Line Inputs, 6 x Mic/Line Inputs, XMAX Microphone Preamps, Flexible Routing & Zero-Latency Monitor, MIDI & SPDIF I/O + BNC Word Clock Out, Includes Software Suite

The Presonus Studio 1824 is a USB 2.0 audio/MIDI interface capable of recording up to 18 simultaneous inputs at up to 24-bit / 192 kHz and offers XMAX Class-A preamps, ADAT I/O, and S/PDIF I/O. Its 18 outputs offer flexible routing with zero-latency DSP-based monitor mixing and control-room integration with the included Studio One Artist for Mac and Windows, and UC Surface for Mac, Windows, iPad, and Android.

The interface features mute and level controls for the main output, two headphone outputs with independent mix streams, a BNC word clock output, and MIDI I/O with 5-pin DIN connectors.

Features:

High-Speed USB 2.0 Computer Interface
24-Bit / 192 kHz
2 x Mic/Instrument/Line Inputs
6 x Mic/Line Inputs
XMAX Microphone Preamps
8 x Channels of ADAT I/O
10 x 1/4″ TRS Balanced Outputs
Flexible Routing & Zero-Latency Monitor
MIDI & SPDIF I/O + BNC Word Clock Out
Includes Software Suite

Specifications

Computer System Requirements
Mac System Requirements	Mac OS X 10.8.5, 64-bit or later Intel i-series, 2 GHz multicore processor (or AMD equivalent) or faster 4 GB RAM (8 GB or more recommended) USB 2.0 port 32 GB hard disk space PreSonus Universal Control 2.0 or later Monitor with 1366 x 768 resolution (high-dpi monitor recommended) Multitouch-enabled monitor required for touch operation
Windows System Requirements	Windows 7 x64/x86 SP1 + platform update, Windows 8.1 x64/x86, Windows 10 x64/x86 Intel i-series 2 GHz multicore processor (or AMD equivalent) or faster 4 GB RAM (8 GB or more recommended) USB 2.0 port 32 GB hard disk space PreSonus Universal Control 2.0 or later Monitor with 1366 x 768 resolution (high-dpi monitor recommended) Multitouch-enabled monitor required for touch operation
iOS System Requirements	iOS 9.3 or later iPad Pro, iPad Air 2, iPad Air, iPad mini 4, iPad mini with Retina display, iPad (4th generation), iPad mini, iPad (3rd generation), iPad 2
Android System Requirements	Android 5.0 (Lollipop) or later Android smartphone (QMix-UC) Android tablet (8-inch) with 1024×768 resolution (UC Surface)

General
Sample Rate	44.1, 48, 88.2, 96, 176.4, 192 kHz
Converters	Converter Resolution: 24-bit Converter Dynamic Range: 114 dB Converter Dynamic Range: 114 dB

Microphone Inputs
Maximum Level	+16 dBu, min gain
Gain Range	80 dB
Frequency Response	20 Hz to 20 kHz (unity gain)
Dynamic Range	110 dB (A-wtd, min gain)
THD + N	0.005% (1 kHz, 0 dBu, unity gain)
EIN	-128 dBu (A-wtd, 20 kHz BW, Rs=150 Ohms, max gain)
Input Impedance	1400 Ohms
Phantom Power	48 V (>10 mA per channel)

Line Inputs
Maximum Level	+21 dBu (balanced, min gain)
Gain Range	40 dB
Frequency Response	20 Hz to 20 kHz (unity gain)
Dynamic Range	112 dB (A-wtd, min gain)
THD + N	0.005% (1 kHz, +18 dBu, min gain)
Input Impedance	10 kOhms

Instrument Inputs
Maximum Level	+15 dBu (unbalanced, min gain)
Gain Range	80 dB
Frequency Range	20 Hz to 20 kHz (min gain)
Dynamic Range	112 dB (A-wtd, min gain)
THD + N	0.020% (1 kHz, +10 dBu, min gain)
Input Impedance	1 MOhm

Outputs
Type	Main and Line Outputs: 1/4″ / 6.35 mm TRS female, DC coupled
Maximum Level	+18 dBu, balanced
Frequency Response	Main and Line Outputs: 20 Hz to 20 kHz
Dynamic Range	108 dB (A-wtd, -60 dBFS)
THD+N	0.004% (1 kHz, -1 dBFS, unity gain)

Headphone Outputs
Maximum Power	150 mW / channel (60 Ohms load)
Frequency Response	20 Hz to 20 kHz (unity gain)
Dynamic Range	103 dB (A-weighted, 1 kHz, unity gain)
THD+N	0.250% (1 kHz, 150 mW, unity gain)
Headphone Impedance Range	32 to 600 Ohms
Dimensions (H x W x D)	1.8 x 19.0 x 5.5″ / 4.4 x 48.3 x 14.0 cm
Weight	4.8 lb / 2.2 kg
