ตู้ลำโพงซับเบส PreSonus CDL18s Dante-Enabled Active Subwoofer 18″
ตู้ลำโพงกลางแจ้งซับเบส PreSonus CDL18s Active Subwoofer ขนาดดอกลำโพง 18 นิ้ว Low-Frequency Driver, มีกำลังขับ 2000 วัตต์ of Class-D Power, ตอบสนองความถี่ 42 to 150 Hz, Max SPL 135 dB, Ground Stack or Fly Rig, Variable Low-Pass Filter, Input/Output XLR + Polarity Invert
ราคาไม่รวมภาษีมูลค่าเพิ่ม…
฿89,000.00
Description
PreSonus CDL18s Dante-Enabled Active Subwoofer 18″ 2000W
ตู้ลำโพงกลางแจ้งซับเบส PreSonus CDL18s Active Subwoofer ขนาดดอกลำโพง 18 นิ้ว Low-Frequency Driver, มีกำลังขับ 2000 วัตต์ of Class-D Power, ตอบสนองความถี่ 42 to 150 Hz, Max SPL 135 dB, Ground Stack or Fly Rig, Variable Low-Pass Filter, Input/Output XLR + Polarity Invert, Network Port Ethernet with Built-In DSP
PreSonus CDL18s Dante-Enabled Active Subwoofer delivers a high-output and controlled performance in sound-reinforcement applications for live stage, theater, clubs, and more. The CDL18s utilizes a 2000W (peak) Class-D amplifier to power the 18″ woofer with a 4″ voice coil, delivering a frequency response of 42 to 150 Hz with a peak SPL of 135 dB.
The 15mm eucalyptus plywood enclosure is coated with a Chemline polyurea finish, a powder-coated steel grille, and offers XLR input and output with polarity invert. The driver and voice coil provide 7mm of driver travel before reaching over-excursion.
The CDL18s easily ground stacks for simplified deployment and up to two subs may be flown with five CDL12 full-range tops for a complete line-array/point source sound system.
Onboard DSP presets help facilitate simplified array configurations, or connect the array via Ethernet to enable WorxControl software for Mac and Windows, which provides compression, limiting, delay, and an 8-band EQ.
Speakers and subs may be grouped and managed separately or together with remote performance monitoring indicators for temperature and signal levels. Additionally, the locking Ethernet connection allow the amplifier to integrate into Dante network environment. The PreSonus CDL18s ships with a powerCON power cord.
Features:
- Adds solid, gutsy bass to your full-range CDL12 system
- 18″ driver unleashes loads of thunderous low end
- 2,000 watts of Class D power exhibit remarkable headroom, explosive SPLs, and incredible dynamics
- Onboard array presets for easy deployment
- Dive into advanced features with Worx Control software
- Speaker-management tools include 8-band EQ, polarity invert, compression, limiting, 800ms of delay, and more
- Built-in Dante connectivity gives you near-zero latency and synchronization
- Boasts an impressive range of pole-mounted and suspended deployment options
Specifications
| Configuration | Active Subwoofer |
| Total Power Capacity | 2000 W Peak 1000 W Program 500 W RMS |
| LF Driver | 1 x 18″ / 45.7 cm Woofer |
| LF Voice Coil | 4″ / 10.2 cm |
| Magnet | Ferrite |
| Frequency Range | 20 Hz to 20 kHz 36 Hz to 144 Hz -10 dB |
| Frequency Response | 42 Hz to 150 Hz -3 dB |
| Maximum SPL | 135 dB |
| Max Input Level | +4 dBu |
| I/O Impedance | Input: 40 kOhms |
| THD | <0.05% |
| Protections | DC, Overcurrent, Overvoltage, Thermal, Undervoltage |
| Audio I/O | XLR Line Input XLR Output |
| Network I/O | 1 x etherCON (Control) |
| Crossover | 90 Hz |
| EQ | Yes |
| Dynamic Processing | Compression, HF Limiter, Limiter |
| Alignment Delay | Yes |
| Phase Adjustment | Yes |
| Max Sample Rate/Resolution | 48 kHz / 24-Bit |
| AC Input Power | 90 to 260 VAC, 50 / 60 Hz |
| AC Power Connector | 1 x powerCON Input 1 x powerCON Output |
| Current Consumption | 4.2 A (1/8 Power) |
| Mounting | 1 x M20 (Top) |
| Handles | 2 x Side |
| Cooling | Convection |
| Construction Material | Metal Grille, Plywood |
| Dimensions | 23.2 x 20.8 x 24.0″ / 589.3 x 528.3 x 609.6 mm |
| Weight | 105 lb / 47.6 kg |
