คอนโทรล์เลอร์ PreSonus ATOM Producer Lab
USB MIDI คอนโทรล์เลอร์ PreSonus ATOM Producer Lab Producer Pack with Atom Pad Controller, AudioBox USB 96 Audio Interface, M7 Condenser Microphone, and Studio One Artist Software
ราคาสินค้าไม่รวมภาษีมูลค่าเพิ่ม
฿11,900.00 ฿10,900.00
Description
PreSonus ATOM Producer Lab: Complete Production Kit
USB MIDI คอนโทรล์เลอร์ PreSonus ATOM Producer Lab Producer Pack with Atom Pad Controller, AudioBox USB 96 Audio Interface, M7 Condenser Microphone, and Studio One Artist Software
The PreSonus ATOM Producer Lab is a complete production kit that combines the ATOM production and performance pad controller with Studio One Artist production software, the AudioBox USB 96 audio/MIDI interface, and the M7 large-diaphragm condenser microphone to create an all-in-one solution for musicians, producers, and engineers wishing to produce professional music.
The ATOM pad controller offers tight integration with Studio One Artist, allowing for virtual instrument and preset browsing, creating loop points and timeline navigation, tempo control, MIDI editing and quantization, zoom, transport controls, and more. The Studio One 4 Artist software is an easy-to-use DAW that delivers unlimited audio tracks, MIDI, virtual instruments, buses, and FX channels. The software offers powerful drag-and-drop functionality and offers a single-window work environment. The software ships with 35 native effects and over 10GB of third-party software, loops, and instruments.
Features:
- Groove box–style pad controller
- 16 velocity- and pressure-sensitive pads with 8 pad banks (128 total sounds)
- Enjoy full expression with switchable polyphonic aftertouch, channel pressure, or MIDI CC message modes
- 4 endless rotary encoders make tweaking parameters a breeze
- Selectable pad velocity curves and pressure thresholds customize the pads’ response for maximum expression
- MIDI keyboard, note repeat, and full velocity modes
- Internal or external clocking and USB 2.0 connectivity
- Deep integration with Studio One DAW software
- Automatically detected by Studio One, so no setup is required
- Create a new track, change an instrument’s preset, or change your project’s tempo right from the hardware
- Set looping points, navigate the timeline, zoom in/out on the timeline or events, and edit/quantize MIDI events
- Benefit from quick access to Studio One’s transport controls
- Also works with other DAWs via USB-MIDI
- Includes Studio One Artist software and a 5′ USB cable
Specifications
| Mac System Requirements | OS: Mac OS X 10.11 or later (64-bit only) CPU: Intel Core 2 Duo processor (Intel Core i3 or faster recommended) Memory: 4 GB RAM (8 GB or more recommended) USB: USB 2.0 port Internet connection (needed for software installation and activation) Monitor: 1366 x 768 resolution (high-dpi monitor recommended) Hard Drive Space: 40 GB Universal Control: 2.9 or later (for firmware updates) Studio One 4.1+ required for native integration |
| Windows System Requirements | OS: Windows 7 (SP1 + platform update), Windows 8.1, or Windows 10 (64-bit only) CPU: Intel Core Duo or AMD Athlon X2 processor (Intel Core 2 Duo or AMD Athlon X4 or better recommended) Memory: 4 GB RAM (8 GB or more recommended) USB: USB 2.0 portInternet connection (needed for software installation and activation) Monitor: 1366 x 768 resolution (high-dpi monitor recommended) Hard Drive Space: 40 GB Universal Control: 2.9 or later (for firmware updates) Studio One 4.1+ required for native integration |
| Input | Connection Type: USB 2.0 (bus-powered) |
| Controls | 16 x full-size velocity- and pressure-sensitive RGB LED pads 20 x assignable buttons 4 x endless rotary knobs 1 x setup button |
| Dimensions (H x D x W) | 0.8 x 7.7 x 8.0″ / 20.8 x 195.1 x 201.9 mm |
| Weight | 1.0 lb / 0.5 kg |
| Frequency Response | Microphone Preamp (±3.0 dB): 20 Hz to 20 kHz Headphone Output (±1.0 dB): 20 Hz to 30 kHz |
| Input Impedance | Microphone Preamp: 1.2 kOhms Line: 0.5 MOhms |
| Output Impedance | Line: 51 Ohms |
| Maximum Output | Headphone: 60 mW/Ch at 60-Ohm load |
| Total Harmonic Distortion (THD) | <0.008% |
| Signal to Noise Ratio | >95 dB |
| CMRR | >45 dB (1 kHz, 55 dB gain) |
| Gain Range | 0 to 35 dB, ±1 dB |
| Maximum Input Level | -3 dBu |
| Connectors | 2 x XLR/TRS combo inputs (mic/line) 2 x 5-pin DIN MIDI I/O 2 x 1/4″ TRS main out (balanced) 1 x 1/4″ TRS headphone 1 x USB Type-B |
| Power | USB bus-powered |
| Phantom Power | +48 V |
| AD/DA | Dynamic Range: 105 dB Bit Depth: 24-bit Reference Level for 0 dBFS: +4 dBu Sample Rates: 44.1, 48, 88.2, 96 kHz |
| System Requirements | Mac: Intel Core Duo processor (Intel Core 2 Duo or Intel Core i3 or faster recommended) OS X 10.8.5 or later 2 GB RAM or more (4 GB recommended) USB 2.0 port 20 GB hard-drive space (internal or external 7200 RPM storage drive highly recommended) 1024 x 768 minimum monitor resolution Internet connection (for activation)Windows: Intel Core 2 processor (Intel Core i3 processor or faster recommended) Windows 7 (x64/x86) SP1, 8, 8.1 (x64/x86), 10 (x64/x86) 2 GB RAM or more (4 GB recommended) USB 2.0 port 20 GB hard-drive space (internal or external 7200 RPM storage drive highly recommended) 1024 x 768 minimum monitor resolution Internet connection (for activation) |
| Dimensions (WxHxD) | 5.5 x 5.5 x 1.8″ / 140 x 140 x 45 mm |
| Weight | 5 lb / 2.7 kg |
| Type | M7: Large-diaphragm condenser |
| Element | Electret |
| Polar Pattern | Cardioid |
| Frequency Response | 40 Hz to 18 kHz |
| Sensitivity | -39 dBV/ap (12.2 mV/pa) |
| Rated Impedance | 200 Ohms |
| Equivalent Input Noise | EIN: 20 dB |
| Maximum SPL | 136 dB SPL |
| Phantom Power Requirement | +12 to +52 VDC, 3 mA |
| Signal to Noise Ratio (SNR) | 74 dB |
| Dynamic Range | 11 dB |
| Current Consumption | 3.5 mA |
| Dimensions (W x L) | Interface: 2.1 x 6.7″ / 5.4 x 17.0 cm |
