ลำโพงห้องอัด NEUMANN KH310-A 3-Way Active Studio Monitor 8.25″
ลำโพงตู้แบบมีกำลังขยายในตัว Neumann KH 310-A ตู้ลำโพงแบบ 3-Way Active ขนาดลำโพง 8.25 นิ้ว Woofer Cone ชัดเจน 3 นิ้วกลาง ผ้า Dome Midrange แหลม 1 นิ้ว Titanium Dome Tweeter, มีกำลังขับ 290 วัตต์ รวม เอาต์พุตต่อเนื่อง,-แอมพลิฟายเออร์ Monitor, ทดสอบรหัส KH310-A L, KH310-A R
ราคาสินค้าเป็นราคาต่อใบ…และไม่รวมภาษีมูลค่าเพิ่ม
฿171,000.00 ฿111,150.00
Description
NEUMANN KH310-Aมอนิเตอร์สตูดิโอ 3-Way Active 8.25″
ลำโพงตู้แบบมีกำลังขยายในตัว Neumann KH 310-A ตู้ลำโพงแบบ 3-Way Active ขนาดลำโพง 8.25 นิ้ว Woofer Cone ชัดเจน 3 นิ้วกลาง ผ้า Dome Midrange แหลม 1 นิ้ว Titanium Dome Tweeter, มีกำลังขับ 290 วัตต์ รวม เอาต์พุตต่อเนื่อง,-แอมพลิฟายเออร์ Monitor, ทดสอบรหัส KH310-A L, KH310-A R
KH 310 Three-Way Active Studio Monitor from Neumann is a tri-amplified monitor capable of a total of 290-watts of continuous output. It is designed for use as a near-field monitor as well as in multi-channel systems as a front or rear loudspeaker, and can be used for tracking, mixing, and mastering applications.
The KH 310 features a 8.25″ woofer, a 3″ midrange driver, and a 1″ tweeter that are housed in a sealed, 3-way cabinet designed to reduce standing waves and assist in fast bass transient response. Neumann’s Elliptical Mathematically Modeled Dispersion (MMD) waveguide was implemented with the application of mixing at a large-format console in mind.
It provides a smoother off-axis response, essentially widening the KH 310’s “sweet spot” and allowing you to move across the console without a decrease in audio quality. Coupled with the 4-position bass, low-mid, and treble acoustic controls, it allows the KH 310 to function ideally in a variety of acoustic environments.
The KH 310 can be mounted in a variety of positions thanks to its integrated mounting points. The included self-adhesive feet help provide stability when mounting on speaker stands.
Features:
- Active three-way studio monitor for near-field or rear-surround use
- For use as a left-channel monitor
- Elliptical MMD waveguide gives you a wider sweet spot and better off-axis response
- Sealed cabinet design for more accurate bass and better transient response
- One-piece front panel reduces diffraction and improves frequency response
- แอมพลิฟายเออร์ Class AB อันทรงพลังช่วยให้คุณมีเฮดรูมสูงและตอบสนองชั่วขณะได้อย่างรวดเร็ว
Specifications
| Monitor Type | Active 3-Way |
| Enclosure | Sealed, Shielded |
| Drivers | HF Driver: 1 x 1″ / 25 mm Tweeter MF Driver: 1 x 3″ / 75 mm Cone LF Driver: 1 x 8.24″ / 210 mm Woofer |
| Amplification | HF Amplifier: Class-AB Rated at 70 W RMS / 90 W Peak MF Amplifier: Class-AB Rated at 70 W RMS / 90 W Peak LF Amplifier: Class-AB Rated at 150 W RMS / 210 W Peak |
| Frequency Range | 34 Hz to 21 kHz ± 3 dB (at -3 dB) |
| Frequency Response | 36 Hz to 20 kHz ± 2 dB |
| Maximum Sound Pressure Level (SPL) | 116.3 dB |
| Total Harmonic Distortion (THD) | 0.5% |
| Maximum Input Level | +24 dBu |
| Analog Input Sensitivity/Gain | 0 to -15 dBu (Continuously Variable) |
| Self-Generated Noise | Less Than 20 dBA (at 3.93″ / 10 cm) |
| Protections and Limiting | Excursion Limiter, Soft Limiter, and Thermal Limiting |
| CMRR | 56 dB |
| EQ | 1 x LF Shelf: -7.5 to 0 dB (2.5 dB Increments) 1 x Low-Mid Notch/Peak: -4.5 to 0 dB (1.5 dB Increments) 1 x HF Shelf: -2 to +1 dB (1 dB Increments) |
| Filters | High-Pass at 15 Hz, 6 dB/Octave Slope |
| Crossover Frequency | Low-Pass Frequency: 650 Hz, 24 dB/Octave Slope High-Pass Frequency: 2 kHz, 24 dB/Octave Slope |
| I/O | 1 x 3-Pin XLR Balanced Analog Input (13 kOhms) |
| AC Input Power | 100 to 240 VAC at 50/60 Hz |
| Power Consumption | 24 W (Idle) 300 W (Maximum) |
| Operating Temperature | 50 to 104°F / 10 to 40°C |
| Operating Humidity | 90% |
| Storage Temperature | -13 to 158°F / -25 to 70°C |
| Enclosure Material | Metal Grille |
| Mounting Points | 2 x M8 (Side Panels) |
| Dimensions (W x H x D) | 15.1 x 10 x 11.5″ / 383 x 253 x 292 mm |
| Weight | 28.6 lb / 13.0 kg |
