ลำโพงห้องอัด NEUMANN KH120-A Studio Monitor 5.25″
ลำโพงสตูดิโอสำหรับห้องอัดเสียง Neumann KH 120-A เป็นตู้ลำโพงแบบ Active ขนาดดอกลำโพง 5.25 นิ้ว Composite Sandwich Woofer Cone, เสียงแหลม 1 นิ้ว Titanium Dome Tweeter, มีกำลังขับ 160 Peak Analog AB Amplifier, ตอบสนองความถี่ 52 Hz to 21 kHz ± 3 dB
ราคาสินค้าเป็นราคาต่อใบ…และไม่รวมภาษีมูลค่าเพิ่ม
฿48,900.00 ฿31,800.00
Description
Neumann KH 120-A Studio Monitor 5.25″ 160W
ลำโพงสตูดิโอสำหรับห้องอัดเสียง Neumann KH 120-A เป็นตู้ลำโพงแบบ Active ขนาดดอกลำโพง 5.25 นิ้ว Composite Sandwich Woofer Cone, เสียงแหลม 1 นิ้ว Titanium Dome Tweeter, มีกำลังขับ 160 Peak Analog AB Amplifier, ตอบสนองความถี่ 52 Hz to 21 kHz ± 3 dB
The Neumann KH 120-A Studio Monitor combines a 1″ titanium fabric dome tweeter powered by 50 W RMS (80 W peak) of analog amplification with a 5.25″ long throw composite sandwich cone bass driver powered by 50 W RMS 80 W peak) analog amplification with dual front panel bass ports. The two speaker drivers are mounted in an elliptical mathematically modeled dispersion waveguide for smoother off-axis response and a more forgiving sound signature in different acoustical environments.
The front panel is made from one piece without discontinuities to reduce diffraction with protective metal grills and the cabinet is made of magnetically shielded aluminum to reduce resonances, improve heat dissipation, and extend the operating lifetime of the unit. The monitor is suitable for professional tracking, mixing, and mastering applications in broadcast, project, and post-production studios.
The system delivers a free field frequency response of 52 to 21,000 Hz with 4-position bass, low-mid, and treble acoustical controls for tailoring the response to different rooms and an input gain control from 0 to -15 dB.
The front panel Neumann logo functions as an LED indicator for power and clip/limiting but can also be dimmed for light applications and for use when placed behind screens. A variety of wall, ceiling, truss, subwoofer, stand, and surface mounting options are available through a range of accessories (sold separately).
Features:
- Compact bi-amplified nearfield studio monitor
- 5.25″ low-frequency driver (50W), 1″ high-frequency driver (50W)
- Elliptical Mathematically Modelled Dispersion (MMD) waveguide provides smooth off-axis response and accurate monitoring in non-ideal acoustical environments
- Powerful titanium fabric dome tweeter delivers low-distortion and high-frequency reproduction
- Composite sandwich cone woofer designs dampen breakup modes and reduce harmonic distortion
Specifications
| Frequency Response | Free Field: 52 to 21,000 Hz ±3 dB Pass Band Free Field: 54 to 20,000 Hz ±2 dB |
| Self Noise | < 20 dB(A) at 10 cm |
| Total Harmonic Distortion (THD) | > 100 Hz (<0.5% at 96 dB SPL at 1 m) |
| Max SPL Level | Full Space: 105.1 dB Half Space at 3% THD at 1 M: 111.1 dBShort Term SPL with IEC-Weighted Noise: 107 dB(C) With Music Material at 2.3 m (pair): 97 dB(C) (full range), 104 dB(C) (with subwoofer)Long Term SPL with Pink Noise at 2.3 M, In Typical Listening Conditions (single/pair): 88/93 dB(C) SPL (full range, 89/94 dB(C) SPL (with subwoofer) |
| Bass Capability | 104.8 dB |
| Amplifier | Woofer: 50 W (80 W peak) Tweeter: 50 W (80 W peak) |
| Controller Design | Analog, active |
| Crossover Frequency | 2,000 Hz |
| Crossover Slope | 24 dB/octave, 4th order |
| Equalization | Bass: 0, -2.5, -5. -7.5 dB Mid: 0, -1.5, -3, -4.5 dB High: +1, 0, -1, -2 dB |
| Protection Circuits | Limiter, low, high |
| Infrasonic filter protection | 30 Hz; 6 dB/octave |
| Impedance | 10 k Ohms in position 94/108 dB SPL at 1 m 20 k Ohms in position 100/114 dB SPL at 1 m |
| Input Gain Control | 0 to -15 dB |
| Output Level Control | 94, 100, 108, 114 dB |
| CMRR | >56 dB at 15,000 Hz |
| Maximum Input Level | 24 dBu |
| Indicators | Power On: Neumann logo “white” Limit/Clip: Neumann logo “red” |
| Power Supply | 100 to 240 V; 50/60 Hz |
| Power Consumption | Idle: 20 W Full Output AC: 200 W |
| Cabinet | Painted aluminum, anthracite (RAL 7021) Powder-coated aluminum, white (RAL 9016) |
| Operating Conditions | +50 to +104° F (+10 to +40° C) <90% relative humidity, non-condensing |
| Drivers | Magnetically Shielded Woofer: 5.25″ (130 mm) Tweeter: 1.00″ (25.0 mm) |
| Mounting | 2x M8 on rear panel |
| Volume | Internal: 6.5 liters External: 9.7 liters |
| Dimensions (H x W x D) | 10.875 x 7.125 x 8.625 (277.0 x 182.0 x 220.0 mm) |
| Weight | 14.1 lb (6.40 kg) |
