ดิจิตอลมิกเซอร์ MIDAS M32R Digital Mixer (discontinued)

Name: ดิจิตอลมิกเซอร์ MIDAS M32R Digital Mixer (discontinued)
Price: 83000.00 THB
Availability: InStock

เครื่องผสมสัญญาณเสียงแบบดิจิตอลสำหรับงาน Live and Studio with 40 Input Channels, 16 MIDAS PRO Microphone Preamplifiers and 25 Mix Buses ปัจจุบันได้เปลี่ยนเป็นรุ่น M32R-LIVE แล้วค่ะ!!

ราคาสินค้ายังไม่รวมภาษีมูลค่าเพิ่มนะคะ…

~~฿150,000.00~~ ฿83,000.00

สอบถามและสั่งซื้อสินค้า

Category: ดิจิตอลมิกเซอร์ (Digital Mixer) Tag: MIDAS

Description

MIDAS M32R (ยกเลิกการผลิต) ปัจจุบันได้เปลี่ยนเป็นรุ่น M32R-LIVE แล้วค่ะ!!

เครื่องผสมสัญญาณเสียงแบบดิจิตอลสำหรับงาน Live and Studio with 40 Input Channels, 16 MIDAS PRO Microphone Preamplifiers and 25 Mix Buses

Midas M32R is a digital mixing console that features 16 Midas PRO microphone preamplifiers, 25 time-aligned and phase-coherent mix buses, 8 digital FX engines, and up to 40 simultaneous input channels when used with an optional networked remote I/O solution such as the Midas DL16 digital stage box. This console is an ideal choice for a multitude of live sound, broadcast, studio recording and post production applications.

The M32R console features 17 Midas PRO motorized 100 mm faders that are rated for 1 million life cycles. Currently able to capture audio at 24-bit, 48 kHz sample resolution, the console is “future-proofed” with 96 kHz capable open architecture, which Midas intends to make available for the line.

The M32R includes an extensive array of on-board effects, featuring 8 stereo, studio-grade effects engines, each assignable to any input, group or output mix bus. Choose from high-end FX modules, including a range of reverbs, delays, EQs, dynamics, and much more. Modeled after some of history’s most iconic and sought-after effects processors such as the Teletronix LA-2A, Urei 1176LN, Fairchild 670, and the Pultec EQP-1a, the M32R’s effects run inside the low-latency, 40-bit floating point environment of the mix engine.

Features:

Live performance and studio recording digital console with up to 40 simultaneous input channels
16 Midas PRO microphone preamplifiers
25 time-aligned and phase-coherent mix buses
AES50 networking allows up to 96 inputs and 96 outputs
Open architecture allows for future 96 kHz operation
192 kHz ADC and DAC converters for outstanding audio performance
Industry-leading design by Bentley Motors Designer
High-performance aluminum and high-impact steel structure
Rack-mount brackets included for ultimate flexibility
40-bit floating point digital signal processing
8 DCA and 6 mute groups
8 digital signal processing effects engines
17 Midas PRO motorized 100 mm faders
Daylight viewable 5″ full-color TFT display screen
Optional expansion cards: ADAT, MADI, Dante
Included, pre-installed USB card allows console to act as 32 x 32 channel USB 2.0 audio interface
DAW remote control emulations of Mackie Control and HUI protocols
Optional wireless remote control with Midas Apps for iPhone and iPad
Auto-ranging universal switch-mode power supply

Specifications

Processing
Input Channels	32 input channels, 8 aux channels, 8 FX return channels
Output Channels	8 / 16
Buses	16 aux buses, 6 matrices, main LRC: 100
Effects Engine	8 / 16, (True Stereo / Mono)
Automation	Internal Show Automation (Structured Cues / Snippets): 500 / 100
Scenes	Internal Total Recall Scenes (Incl. Preamplifiers and Faders): 100
Signal Processing	40-bit floating point
A/D and D/A Conversion	A/D Conversion (8-channel, 96 kHz Ready): 24-bit, 114 dB dynamic range, A-weighted D/A Conversion (stereo, 96 kHz Ready): 24-bit, 120 dB dynamic range, A-weighted
Latency	0.8 ms, (I/O, console input to output) 1.1 ms, (network latency, stage box in > console > stage box out)

Connectors
Preamplifier	Midas PRO Series Microphone Preamplifiers (XLR): 16
Talkback	Talkback Microphone Input (XLR): 1
RCA	RCA Inputs / Outputs: 2 / 2
Audio Out (XLR)	XLR Outputs: 8
Monitoring Outputs	Monitoring Outputs (XLR / ¼” TRS Balanced): 2 / 2
Auxiliary	Aux Inputs/Outputs (¼” TRS Balanced): 6 / 6
Headphones	Phones Output (¼” TRS): 1 (Stereo)
Networking	AES50 Ports (Klark Teknik SuperMAC): 2 Ultranet P-16 Connector (No Power Supplied): 1
Expansion	Expansion Card Interface: 32 Channel Audio Input / Output
MIDI	MIDI Inputs / Outputs: 1 / 1
USB	USB Type A (Audio and Data Import / Export): 1 USB Type B: 1, rear panel, for remote control
Ethernet	RJ45: 1, rear panel, for remote control

Microphone Inputs
Design	Midas PRO Series
THD+N	THD+N (0 dB gain, 0 dBu output): <0.01% unweighted THD+N (+40 dB gain, 0 to +20 dBu output): <0.03% (unweighted)
Input Impedance	Input Impedance (Unbalanced / Balanced): 10 kOhms / 10 kOhms
Maximum Input Level	Non-Clip Maximum Input Level: +23 dBu
Phantom Power	+48 V, (switchable per input)
Equivalent Input Noise	@ +45 dB gain (150 ohm source): -125 dB (22 Hz – 22 kHz, unweighted)
CMRR	CMRR @ Unity Gain (Typical): >70 dB CMRR @ 40 dB Gain (Typical): >90 dB

Input/Output
Frequency Response	@ 48 kHz Sample Rate: 0 to -1 dB (20 Hz – 20 kHz)
Dynamic Range	Analog In to Analog Out: 106 dB (22 Hz – 22 kHz, unweighted) A/D, Preamplifier and Converter (Typical): 109 dB (22 Hz – 22 kHz, unweighted) D/A, Converter and Output (Typical): 109 dB (22 Hz – 22 kHz, unweighted)
Crosstalk Rejection Typically @ 1 kHz	100 dB, adjacent channels
Output Level	XLR Connectors (Nominal / Maximum): +4 dBu / +21 dBu
Output Impedance	XLR Connectors (Unbalanced / Balanced): 50 ohms / 50 ohms TRS (Unbalanced / Balanced): 50 ohms / 50 ohms Phones Output Impedance / Maximum output Level: 40 ohms / +21 dBu (Stereo)
Input Impedance	TRS Connectors (Unbalanced / Balanced): 20 kOhms / 40 kOhms
Maximum Input Level	Non-Clip Maximum Input Level, TRS Connectors: +21 dBu
Output Level	TRS (Nominal / Maximum): +4 dBu / +21 dBu
Residual Noise	Residual Noise Level, Out 1-16 XLR Connectors, Unity Gain: -85 dBu 22 Hz – 22 kHz unweighted Residual Noise Level, Out 1-16 XLR Connectors, Muted: -88 dBu 22 Hz – 22 kHz unweighted Residual Noise Level, TRS and Monitor out XLR Connectors: -83 dBu 22 Hz – 22 kHz unweighted

Display
Screens	Main Screen: 5″ TFT LCD, 800 x 480 resolution, 262 k colors Channel LCD Screen: 128 x 64 LCD with RGB color backlight Main Meter: 18-segment (-45 dB to clip)
