ตู้ลำโพง JBL PRX835W Powered Speaker 15″ with Wi-Fi

ตู้ลำโพงกลางแจ้ง JBL PRX 835W 3-Way Full-Range แบบมีแอมป์ขยายในตัว 1500-watt class-D ขนาดดอกลำโพง 15″ Woofer, 6.5″ Mid, 1.5″ Compression ตอบสนองความถี่ 48 Hz to 20 kHz สามารถควบคุม DSP Parameters ผ่าน Wi-Fi ได้ทั้ง iOS และ Android

ราคาไม่รวมภาษีมูลค่าเพิ่ม….เป็นราคาใบละ

฿105,500.00 ฿63,900.00

สอบถามและสั่งซื้อสินค้า

Description

JBL PRX835W 15″ 3-Way Full-Range Powered Loudspeaker with Wi-Fi

ตู้ลำโพงกลางแจ้ง JBL PRX 835W 3-Way Full-Range แบบมีแอมป์ขยายในตัว 1500-watt class-D ขนาดดอกลำโพง 15″ Woofer, 6.5″ Mid, 1.5″ Compression ตอบสนองความถี่ 48 Hz to 20 kHz สามารถควบคุม DSP Parameters ผ่าน Wi-Fi ได้ทั้ง iOS และ Android

The PRX835W from JBL is a 3-way powered loudspeaker designed for main PA applications with extensive Wi-Fi control over the on-board DSP. Well suited for event halls, bands, DJ systems, clubs, bars, schools, and churches, the speaker utilizes two 750W Class-D amplifiers delivering a total of 1500W to the 15″ woofer, 6.5″ mid-frequency driver, and 1.5″ compression driver, which combine to offer a frequency range of 41 Hz to 20 kHz at 138 dB maximum SPL output.

The built-in Wi-Fi offers wireless control of the system from anywhere in the venue using the free PRX Connect app for iOS and Android devices. The app controls levels, an 8-band parametric EQ, user presets, and up to 50ms of user-defined delay to fine-tune your setup. The durable 18mm plywood enclosure is coated with an Obsidian DuraFlex finish and a powder-coated steel grille with acoustical transparent black-cloth backing.

Features:

  • Built in Wi-Fi for wireless control of your system from anywhere in the venue
  • Free PRX Connect mobile app provides wireless control over levels, parametric EQ, user presets, and up to 50ms of user delay to fine-tune your sound
  • Class-leading 1500-watt amplifier delivers ample power to fill your venue
  • JBL Differential Drive transducers for higher SPL in a lightweight design
  • Next-generation JBL neodymium compression drivers
  • Crown-designed input panel with XLR, 1/4”, and RCA inputs, plus XLR loop-through
  • Durable construction with wooden cabinets, tour-proven DuraFlex finish, and dent-resistant cloth-backed 16-gauge grilles
  • Universal power supply for worldwide compatibility
  • Demanding 100-hour test regimen ensures reliable performance
  • Intelligent variable-speed fan activates only when needed to reduce noise
  • Scalable system that integrates with other JBL portable powered PAs

Specifications

System
System Type Self-Powered 15.0″ / 38.1 cm, three-way, bass-reflex
Max SPL Level 138 dB peak
Frequency Range Frequency Range (-10 dB)
Normal: 41.0 Hz to 20.0 kHz
Boost: 41.0 Hz to 20.0 kHz
Frequency Response ± 3dB Normal: 50.0 Hz to 18.3 kHz
Boost: 48.0 Hz to 20.0 kHz
Input Connectors 2 x Balanced combo XLR-1/4″ / 6.35 mm input
2 x unbalanced RCA input
Input Impedance 20 kOhms (balanced)
10 kOhms (unbalanced)
Signal Indicator Limit: Yellow LED indicates peak output has been reached and DSP limiter is acting
Signal: Green LED indicates signal present
Power: Blue indicates system has power and ready to pass audio
EQ Section User-selectable presets for Main or Monitor position, Advanced EQ settings available using Wi-Fi and PRX Connect application
Dynamics dbx Type IV limiter circuit
Crossover Frequency 580 Hz, 2.1 kHz
Amplifier
Design Highly efficient Class-D amplifier
Power Rating 1500 W (750 W x 2)
AC Power 100 to 240 VAC ~ 50/60 Hz
Speaker
LF Driver 1x JBL 275G (15.0″ / 38.1 cm) woofer
MF Driver 1x JBL 196H 165 mm (6.5″ / 16.5 cm) horn-loaded mid-range transducer
HF Driver 1x JBL 2408H-2 (1.5″ / 3.8 cm) annular polymer diaphragm, neodymium compression driver
Coverage Pattern 90 x 50° nominal
Directivity Directivity Index (DI): 10.5 dB
Directivity Factor (Q): 11.2 dB
Enclosure Asymmetrical, 18 mm, plywood
Suspension / Mounting 12x M10 suspension points
Transport and Storage 2x injection-molded handle with backing cup
Finish and Grille Color Finish: Obsidian DuraFlex finish
Grille: Powder-coated, Obsidian, 16-gauge perforated steel with acoustical transparent black-cloth backing
Dimensions (H x W x D) 36.9 x 17.5 x 21.2″ / 93.7 x 44.5 x 53.8 cm
Weight 77.0 lb / 34.9 kg
Packaging Info
Package Weight 89.0 lb
Box Dimensions (LxWxH) 39.0 x 25.5 x 21.0″
