ลำโพงติดฝ้าเพดาน JBL CONTROL 322CT Ceiling Loudspeaker 12″

Description

JBL Control 322CT Coaxial Ceiling Loudspeaker with HF Compression Driver 400 W

ลำโพงติดฝ้าเพดาน JBL CONTROL 322CT ขนาดดอกลำโพง 12 นิ้ว Kevlar-reinforced cone with 3″ voice coil, 1.5″ diaphragm and neodymium magnet for compression driver, ทนกำลังขับ 400 วัตต์, ตอบสนองความถี่ 48 Hz – 19 kHz, +/-3dB (in ceiling)

The JBL Control 322CT is a coaxial point source design ceiling loudspeaker with a built-in 70V/100V multi-tap transformer, featuring a 12″ low frequency cone performing as a waveguide for the high frequencies. The unique metal throat provides seamless transition to the horn, eliminating any aberrant HF “beaming”, and resulting in consistent 90° coverage on a broadband basis with true coaxial behavior.

Features:

• Coaxial ceiling speaker with medium format compression driver and consistent 90° broadband pattern control
• Built-in 70V/100V multi-tap transformer with 12.5W/25W/50W/100W 70V taps and 25W/50W/100W 100V taps
• 12″ Kevlar-reinforced cone with 3″ voice coil, 1.5″ diaphragm and neodymium magnet for compression driver
• 400-watt power handling with high sensitivity and high SPL capability
• Advanced high-slope crossover network for constant coverage and natural midrange
• Baffle equipped with EZRail(TM) feature, holds baffle in place while securing to backcan with screws
• Removable multi-pin locking connector with screw-down terminals for simplified pre- or re-wiring during installation
• Recommended for applications requiring speech and vocal clarity, extended frequency response for foreground and background music
