ลำโพงสตูดิโอ GENELEC 1032C SAM Studio Monitor 10″

Name: ลำโพงสตูดิโอ GENELEC 1032C SAM Studio Monitor 10"
Price: 110000.00 THB
Availability: InStock

ลำโพงมอนิเตอร์สำหรับห้องบันทึกเสียงแบบมีกำลังขยาย (Active) GENELEC 1032C SAM Smart Active Monitor (SAM™) Systems, ขนาดดอกลำโพง 10 นิ้ว woofer เสียงแหลม 1 นิ้ว tweeter, มีกำลังขับ Woofer 200 วัตต์

ราคาสินค้าเป็นราคาใบละ…Contact Us…

฿110,000.00

สอบถามและสั่งซื้อสินค้า

Category: ลำโพงห้องบันทึกเสียง (Studio Monitor) Tag: GENELEC

Description

GENELEC 1032C SAM Studio Monitor 10″ 350W

The Genelec 1032C SAM Studio Monitor is designed for high-powered, near-field monitoring in pro-audio scenarios such as music studios, mobile vans, surround sound systems, multimedia installations, and TV broadcast facilities. The speaker consists of a 10″ bass woofer, a 1″ metal dome tweeter, an active crossover, and a directivity control waveguide to balance the frequency spectrum.

The monitor can accept both analog and digital AES/EBU signals from separate XLR jacks, and automatically detect what kind of audio is being fed into the monitor. To coordinate multiple 1032Cs, you can use Genelec’s GLM software to tune your monitor to your room, daisy-chain monitors, override automatic signal-source selection, and more. Routing is accomplished by means of a few Cat5 cables and a GLM adapter, which are available separately. You’ll note that RJ45 ports are provided for GLM connectivity. An XLR output jack is on hand for sending identical copies of incoming AES/EBU signals to other monitors.

The 1032C provides a 10″ bass woofer amplified by 200W of short-term power, and can play down to 40 Hz. The 1″ metal dome tweeter can play up to 23 kHz, is amplified by 150W of short-term power, and utilizes the directivity control waveguide to achieve phase and delay uniformity. Both the woofer and tweeter are magnetically shielded. The monitor provides you with multiple controls to optimize system performance for your particular listening environment. These controls are enumerated in the features section.

Features:

Smart Active Monitor (SAM™) Systems
Directivity Control Waveguide (DCW™) Technology
Room Response Compensation
Active Crossovers
Protection Circuitry
Optimized Amplifiers
Intelligent Signal Sensing (ISS™) Technology

Specifications

Cut-Off Frequency	Lower: < 33 Hz at -6 dB Upper: > 23 kHz at -6 dB
Frequency Response	40 Hz to 20 kHz (±2.5 dB)
SPL	SPL (Max Short Term): ≥ 114 dB (short term sine wave acoustic output on axis in half space, averaged from 100 Hz to 3 kHz at 3.3′ / 1 m)SPL (Max Long Term): 104 dB SPL maximum (long-term RMS acoustic output in the same conditions with IEC weighted noise (limited by driver protection circuit) at 3.3′ / 1 m)
Peak Output Capacity	124 db maximum peak acoustic output (per pair in listening room with with music material at 3.3′ / 1 m)
Self-Generated Noise Level	≤ 5 dB, in free space at 3.3′ / 1 m on axis (A-weighted)
Harmonic Distortion	< 1% (at 85 dB SPL at 3.3′ / 1 m on axis, 50 to 100 Hz) < 0.5% (at 85 dB SPL at 3.3′ / 1 m on axis, > 100 Hz)
Drivers	Bass: dual 9.8″ / 250 cone Treble: 1.0″ / 25 mm metal dome
Amplifier	Bass Amplifier Short-Term Output Power: 200 W Treble Amplifier Short-Term Output Power: 150 W(Long-term output power is limited by driver protection circuitry)
THD	< 0.05% at nominal output
Digital Connections	AES/EBU Input: XLR female, 110 Ohms AES/EBU Thru/Output: XLR male, 110 Ohms
Sample Rate and Resolution	32 to 192 kHz / 16- to 24-bit
Digital Input	Sensitivity: -30 dBFS Gain Sensitivity: Adjustable from +6 to -6 dBu via rotary control
Network	Type: GLM (proprietary) Connection: 2 x RJ45
Crossover Frequencies	1.8 kHz
Digital Controls	GLM Software Frequency Response Adjustment Parametric Notch Filters: 16x Shelving Filters: 2 x LF and 2 x HF System Room Response Calibration: Genelec GLM AutoCal, GLM manual, Standalone
Mains Voltage	100 to 240 VAC 50/60 Hz
Power Consumption	ISS Active: < 1 W Idle: 11 W Full Output (Short Term): 200 W
Analog Input	XLR female, balanced 10 kOhm (pin 1: ground, pin 2: non-inverting, pin 3: inverting)
Input Impedance	10 kOhms
Analog Input	Maximum Analog Input Level: +25.0 dBu Analog Input Sensitivity: -6 dBu (100 dB SPL at 3.3′ / 1 m) Analog Input Sensitivity: Adjustable from +6 to -6 dBu via rotary control
Dimensions (H x W x D)	19.5 x 12.6 x 11.4″ / 495.0 x 320.0 x 290.0 mm
Weight	37.5 lb / 17.0 kg
