Di Box KLARK TEKNIK DN200 V2 Direct Box
ไดเร็กบ๊อกซ์ KLARK TEKNIK DN200 V2 Direct Box Sum and split options for flexible signal routing Global 20 dB input pad and earth lift switches
ราคาสินค้าไม่รวมภาษีมูลค่าเพิ่ม…..
฿7,500.00 ฿7,100.00
Description
Direct Box KLARK TEKNIK DN200 V2 Active Stereo DI Box
ไดเร็กบ๊อกซ์ KLARK TEKNIK DN200 Direct Box Sum and split options for flexible signal routing Global 20 dB input pad and earth lift switches, Aluminium extrusion casing with protective silicone rubber sleeve
The DN200 Active Stereo Direct Injection Box from Klark Teknik is a dual-channel and multi-mode stereo DI box that delivers superior connectivity and audio performance.
Housed in a robust alloy case with the same form factor as the DN100 Single-Channel DI, and further protected by a replaceable silicon sleeve, the DN200 features inputs on pairs of XLR, TRS, and RCA sockets, plus a switchable 20 dB pad and a ground lift switch.
In addition, the DN200 can operate in Sum mode, where left and right input signals are merged and routed to both left and right outputs, or Split mode, routing the left input signal to both the left and right outputs. The DN200 supports 24 to 48V phantom-power operation.
Features:
- High headroom design with +48 V phantom power for extended dynamic range
- Sum and split options for flexible signal routing
- Fully transformer-isolated design ensures electrical separation between PA and stage equipment
- Balanced line inputs on Neutrik Combo* XLR and high impedance 1/4″ TRS connectors
- RCA Phono inputs for connection of consumer audio equipment
- Independent phantom powering for each channel for maximum reliability
- Global 20 dB input pad and earth lift switches
- Aluminium extrusion casing with protective silicone rubber sleeve
- Compact and rugged design
- Designed and engineered in England
Specifications
| Inputs | |
| Type | Active electronic, balanced or unbalanced |
| Impedance | 1 MΩ nominal, balanced or unbalanced (¼ ” TRS connectors), 20 kΩ (XLR input, RCA Phono input) |
| Connectors | 2 Neutrik Combo XLR/¼ ” TRS input connectors with parallel linked RCA Phono input connectors and ¼ ” TRS linked outputs connectors |
| Maxmum level | +30 dBu (with pad enabled) |
| Attenuator | 20 dB pad |
| Outputs | |
| Type | Transformer balanced |
| Impedance | 75 Ω |
| Connector | 3 pin XLR |
| Max. Level | +10 dBu with load >2 kΩ |
| Min. load | 600 Ω |
| Performance | |
| Noise | -100 dBu, 20 Hz to 20 kHz unweighted, with input terminated by 10 kΩ resistor |
| Frequency response | +0.5/-1 dB 20 Hz to 20 kHz |
| Distortion (THD+N) | <0.01% @ 1 kHz, +4 dBu |
| Power Requirement | |
| Voltage | +48 V Phantom* |
| Current consumption | <20 mA (Both channels) |
| Weight | |
| Net | 0.95 kg |
| Dimensions | |
| Length | 143 mm (5.6 inch) |
| Width | 106 mm (4.2 inch) |
| Height | 59.2 mm (2.3 inch) |
