คอมเพรสเซอร์ dbx 160AD Compressor Gate
อุปกรณ์ปรับแต่งเสียง dbx 160AD Compressor/Limiter Input: Connector: 1⁄4” TRS and XLR, Floating Balanced; XLR: Pin 2 hot ตอบสนองความถี่ที่ 20Hz —20kHz, +0, -0.5dB; +0, -3dB 0.5Hz and 90kHz.
ราคาสินค้าไม่รวมภาษีมูลค่าเพิ่ม…..
฿29,600.00 ฿26,640.00
Description
dbx 160AD Compressor Gate
อุปกรณ์ปรับแต่งเสียง dbx 160AD Compressor/Limiter Input: Connector: 1⁄4” TRS and XLR, Floating Balanced; XLR: Pin 2 hot ตอบสนองความถี่ที่ 20Hz —20kHz, +0, -0.5dB; +0, -3dB 0.5Hz and 90kHz.
dbx 166 xs is a dual channel compressor/gate/limiter that when added to a live sound rig or studio, will deliver more polished, professional sound. The unit can function either as a stereo processor or in dual mono mode and features all the usual controls required for this kind of processor.
The unit provides the ability to smooth out uneven levels, add sustain to guitars and fatten up drums. It also makes it easy to bring vocals to the front of a mix. The PeakStop limiter helps protect expensive amplifiers and speakers by providing an absolute ceiling for peak excursions or large transients that could damage the equipment.
For simplified operation the 166xs features Overeasy compression technology for smooth and musical performance, while the exclusive AutoDynamic attack and release controls puts great sound within easy reach. The processor has true RMS power summing and features quality input and output connectors. Comprehensive visual feedback is provided by gain reduction metering and backlit switches.
Features:
- Error proof operation to smooth uneven levels, add sustain to guitars, fatten drums or tighten up mixes
- New gate timing algorithms ensure the smoothest release characteristics
- Program-adaptive expander/gates
- PeakStop limiter provides an absolute ceiling for peak excursions or large transients for protecting downstream equipment
- Great sounding dynamics control for any type of program material
- Separate precision LED displays for gain reduction, compression threshold and gate threshold allow quick, accurate setup
- Stereo or dual-mono operation
- Balanced inputs and outputs on 1/4″ TRS and XLR connectors
- Side Chain insert
- Classic dbx “Auto” mode
Specifications
| Input Connectors | 1/4″ TRS and XLR, Floating Balanced; XLR: Pin 2 hot Phone: Tip Hot |
| Input Impedance | 40k |
| Max Input | +24dBu, Balanced or Unabalanced (Absolute) |
| CMRR | >45dB (any Frequency) |
| Detector Input | Connector: 14″ TRS phone, Floating Balanced |
| Detector Input Impedance | >200k |
| Detector Input Max Level | +28dBu, Balanced or Unbalanced |
| Output Connectors | 1/4″ TRS phone, Unbalanced; XLR, floating balanced; pin 2 hot |
| Output Impedance | Balanced 200 ohm, unbalanced 100 ohm |
| Max Output | (Balanced): +24dBm; <0.3% THD; (Unbalanced): +20dBm; <0.3% THD |
| Noise | <-90dBu, Unweighted (20Hz – 20kHz) |
| Frequency Response | 20Hz -20kHz, +0, -0.5dB; +0, -3dB 0.5Hz and 90kHz. |
| THD | <0.2%, Typical, any amount of compression up to 40dB @ 1kHz |
| Compressor Threshold Range | -40dBu to +20dBu |
| Compressor Threshold Characteristic | OverEasy® or hard knee |
| Compressor Ratio | Variable 1:1 to :1 thru to -1:1; >60dB maximum compression |
| Compressor Attack Time | Program dependent; typically 15ms for 10dB, 5ms for 20dB, 3ms for 30dB |
| Compressor Release Time | Program Dependent; Typically 8ms for 1dB, 80ms for 10dB, 400ms for 50dB; 125dB/sec rate |
| Dynamic Range | >113dB |
| Gain Adjustment Range | Variable from -20dB to +20dB |
| Stereo Coupling | True RMS Power summing |
| Summing | 1/4″ TRS phone jack |
| Operating Voltage | DO: 90-130VAC, 50/60Hz; EU: 200-250VAC, 50/60Hz |
| Power Connector | IEC receptacle |
| Dimensions | 1.75″ x 19″ x 6.5″ (4.45cm x 48.2cm x 16.51cm) |
| 设备重量 | 4.452 lbs (1.99 kg) |
| Shipping Weight | 6.62 lbs (2.99 kg) |
