แอมป์ขยายหูฟัง BEHRINGER AMP800 Headphone Amplifier
เครื่องขยายสัญญานหูฟัง MINIAMP AMP800 เป็น Headphone Amp แบบสเตอริโอ 4 ch เหมาะสำหรับงาน monitor บนเวทีและห้องบันทึกเสียง
ราคาไม่รวมภาษีมูลค่าเพิ่ม…..
฿3,000.00
Description
BEHRINGER MINIAMP AMP800 Ultra-Compact 4-Ch Stereo Headphone Amplifier
เครื่องขยายสัญญานหูฟัง MINIAMP AMP800 เป็น Headphone Amp แบบสเตอริโอ 4 ch เหมาะสำหรับงาน monitor บนเวทีและห้องบันทึกเสียง
The Behringer AMP800 is an inexpensive, highly compact 4-channel headphone amplifier designed for stage or studio headphone monitoring. The unit features 8 individual headphone outputs, LED input and individual channel metering, dual balanced stereo inputs with separate balance and level control, and dedicated level knobs and input selector switches for each output channel.
Features:
- Ultra-compact headphone amplifier system for studio and stage applications
- 4 independent stereo high-power amplifier sections
- Highest audio quality with virtually all types of headphones even at maximum volume
- Phones Level control plus accurate 6-segment LED output meter per channel for easy level monitoring
- 2 balanced stereo main inputs with independent Level and Balance controls for individual mixes, selectable for all 4 headphone amplifiers
- Accurate 6-segment LED main level meter for precise level indication of both line inputs
- 2 headphone outputs per channel (front and rear panel) allow a total of 8 headphones to be simultaneously connected
- Parallel Link Output allows cascading of several headphone amplifiers
- High-quality potentiometers and illuminated switches for long-term reliability
- All Mini Series models can be stacked on top of each other to create an ultra-compact signal processor solution
Specifications
| Number of Channels | 4 |
| Input Connections | 4 x 1/4″ TRS Phone (L,R Pairs), Balanced |
| Output Connectors | 2 x 1/4″ TRS Phone L,R Link, Balanced 4 x 1/4″ TRS Headphone, Rear Panel 4 x 1/4″ TRS Headphone, Front Panel |
| Maximum Output Level | +21dBm/124mW (100 Ohm load) |
| Function Controls | 2 x A,B Input Balance Knobs 2 x A,B Input Level Knobs 4 x Individual Phones Level Knobs 4 x Channel Input Selector Switches 1 x Power Switch |
| Frequency Response | 10 Hz – 120 kHz, -3dB |
| THD + N | 0.007% (100 Ohm load) |
| Noise | <95dB, 10Hz – 20kHz @ 0dBu, A-weighted |
| Display | 6-segment LED Bargraphs |
| Dimensions | 9.5 x 1.9 x 4.7″ (242.6 x 48 x 120mm) |
| Weight | 1.09 lb (494 g) |
| Specialties | Separate Front and Rear 4-Channel Headphone Outputs Ultra-Compact Bargraph LED Metering |
