เพาเวอร์แอมป์ BEHRINGER A500 Power Amplifier
เพาเวอร์แอมป์ A500 Ultra-linear power amplifier for recording studios post-production live sound and HiFi application 2 x 300 Watts into 4 Ohms, 600 Watts
ราคาสินค้าไม่รวมภาษีมูลค่าเพิ่ม
฿9,900.00
Description
เพาเวอร์แอมป์ BEHRINGER A500 2 x 300 W
2-Channel Rackmount Ultra-Linear Studio Power Amplifier
The Behringer A500 is an inexpensive professional reference power amplifier, targeted primarily toward recording studio applications, but viable as an installation solution as well. The unit features bar-graph level metering, independent thermal overload protection for each channel, 230 Watts of power output per side at 4 Ohms, and fan-free convection cooling for minimal operating noise.
- 2-channel ultra-linear rackmount power amplifier for studio and installation applications with 230W output per side at 4 Ohms
- Servo-controlled design, fan-free convection cooling for quiet operation
- Bar graph level metering with clip and protection indicators
- High-power Toshiba/Fairchild transistors, high-current, low-noise toroidal transformer
- Independent thermal overload protection for each channel for automatic speaker and amplifier protection
- Full complement of input connectors with balanced XLR, 1/4″, unbalanced RCA
Features:
- Ultra-linear power amplifier for recording studios, post-production, live sound and HiFi application
- 2 x 300 Watts into 4 Ohms, 600 Watts into 8 Ohms in bridged mono operation
- Servo-controlled design can drive virtually any passive speaker such as studio monitors, etc.
- Advanced convection-cooling for absolutely noise-free and stable operation (no fan)
- Precise level meter and clip indicators for accurate performance monitoring
- Input connections on balanced XLR, 1/4” TRS and RCA connectors
- Speaker outputs on professional ”touch-proof” binding posts and 1/4” TS connectors
- Ultra-reliable Toshiba* / Fairchild* power transistors
- Independent thermal overload protection with LED indicator for each channel automatically protects amplifier and speakers
- High-current toroidal transformer for absolute reliability and lowest noise interference
- Conceived and designed by BEHRINGER Germany
Specifications
Behringer A500
| Power Rating | Stereo @ 8 Ohms: 160 Watts
Stereo @ 4 Ohms: 230 Watts Bridged Mono @ 8 Ohms: 500 Watts |
| Damping Factor | Not Specified by Manufacturer |
| Input Sensitivity | 1.3V (+4.5dBu, VRMS @ 4 Ohms) |
| Input Impedance | 10 kOhms, Unbalanced
10 kOhms, Balanced |
| Gain | 28 dB |
| Frequency Response | 10 Hz – 25 kHz, +0/-1dB |
| Signal-to-Noise Ratio | -100dB, unweighted, 20Hz – 20kHz |
| Total Harmonic Distortion (THD) | <0.01% |
| Input Connections | 2 x 3-pin XLR, Balanced
2 x 1/4″ TRS Phone, Balanced 2 x RCA Phono, Unbalanced |
| Output Connectors | 2 x 1/4″ TS Phone(Output 1,2)
1 x 1/4″ TS Phone(Bridged Mono) 4 x Touch-Proof Binding Posts |
| Controls Front Panel | 2 x Rotary Volume Controls
1 x Power Switch |
| Controls (Rear) | 1 x Stereo/Bridge Mono Switch |
| Indicators | 1 x Yellow Protection LED
1 x Red Clip LED 1 x White Power on LED |
| Cooling | Convection-cooled |
| Power Consumption | 6.5A (120VAC, 60 Hz)
3.6A(230VAC, 50Hz) |
| Dimensions | 19 x 10.8 x 4″ (482.6 x 257.5 x 101.6mm) |
| Weight | 18.5 lb (8.4 g) |
| Specialties | Convection-cooled
LED Bar Metering |
